6" Dia. X 1/2" Center Hole Type E 304 SS Dispersion Blade
Model Number: DB6E
Part Number: 21C1206
Our Design E blade has a unique "knife edge" profile for shredding or breaking down larger solid materials such as wax or rubber. When combined with the more standard tooth design this blade is the choice for applications requiring a chopping and dispersion action in a single process. The 6" diameter blade (measured bent blade tip to bent blade tip) is laser cut from 304 stainless steel, has a 1/2" center hole and is die formed. We can provide 316 stainless steel blades by request. For increased blade life or for highly abrasive applications please see our tungsten carbide coated models. All our dispersion blades can be supplied with mounting hole patterns to match your equipment requirements. Optional mounting hubs are also available and include welded or bolted designs. Please see our guide to ordering dispersion blades or contact customer service.
Impeller
| Diameter | 6" |
| Style | Dispersion Blade |
| Center Hole | 1/2" |
| Design | E |
| Material Construction | 304 Stainless Steel |
| Surface Finish | 2B |
General
| Warranty | 1 Year Warranty against defective materials and workmanship. All component parts of our products are covered by this warranty, except for normal wear items such as belts or impellers. |
| Weight | 2 |
| Shipping Carrier | Small Parcel |
| FOB | New Albany, IN |
Model Number: DB6E
Our Design E blade has a unique "knife edge" profile for shredding or breaking down larger solid materials such as wax or rubber. When combined with the more standard tooth design this blade is the choice for applications requiring a chopping and dispersion action in a single process. The 6" diameter blade (measured bent blade tip to bent blade tip) is laser cut from 304 stainless steel, has a 1/2" center hole and is die formed. We can provide 316 stainless steel blades by request. For increased blade life or for highly abrasive applications please see our tungsten carbide coated models. All our dispersion blades can be supplied with mounting hole patterns to match your equipment requirements. Optional mounting hubs are also available and include welded or bolted designs. Please see our guide to ordering dispersion blades or contact customer service.
Impeller
| Diameter | 6" |
| Style | Dispersion Blade |
| Center Hole | 1/2" |
| Design | E |
| Material Construction | 304 Stainless Steel |
| Surface Finish | 2B |
General
| Warranty | 1 Year Warranty against defective materials and workmanship. All component parts of our products are covered by this warranty, except for normal wear items such as belts or impellers. |
| Weight | 2 |
| Shipping Carrier | Small Parcel |
| FOB | New Albany, IN |
3 Business Days * Orders in quantity or with other items may extend lead times.
